Analysis of low insertion loss and high transmission performance of Cat6 Unshielded Module
1. What is insertion loss and its impact on network transmission?In the process of network transmission, insertion loss refers to the signal attenuation caused by resistance, poor contact or other factors when the signal passes through the network components. The lower the insertion loss, the more efficient the signal transmission between network devices, and the less signal attenuation, which means that the network transmission quality is more stable. For Cat6 Unshielded Module, low insertion loss is one of the cores of its design. Through precise contact design and high-quality material selection, the module can effectively reduce signal loss, so that the network signal can be transmitted more clearly and stably. 2. Technical advantages of low insertion lossCat6 Unshielded Module can achieve low insertion loss, first of all, thanks to its precise contact design and cold pressing technology. Cold pressing technology minimizes the resistance during signal transmission by achieving efficient electrical contact between the terminal and the circuit board, thereby reducing signal loss. In addition, the module also uses high-quality materials to ensure the stability and reliability of the contact point during long-term use. Compared with traditional modules, Cat6 modules have lower insertion loss values during signal transmission, which is crucial to ensure the stability of high-frequency signals in large-scale network systems. Under the high requirement of 250MHz bandwidth, low insertion loss technology ensures that data can pass through the network with lower loss and higher speed, thereby supporting a variety of high-speed network protocols including 10Base-T, 100Base-Tx, 1000Base-Tx, etc. 3. Core technology of high transmission performanceIn addition to low insertion loss, another outstanding feature of Cat6 Unshielded Module is its excellent high transmission performance. The cold pressing technology and precision contact point design adopted by the module ensure efficient and stable signal transmission, avoiding signal attenuation caused by poor contact. High transmission performance enables the module to effectively support high-frequency bandwidth and reach a transmission frequency of 250MHz, thus meeting the needs of high-speed networks such as 10Base-T, 100Base-Tx, 1000Base-Tx, ATM (155Mbps and 622Mbps). In network equipment, especially in scenarios where large amounts of data need to be transmitted, high transmission performance is the key to ensuring fast response and efficient processing. For example, in data centers or enterprise network environments, it is often necessary to support multiple devices to access and exchange high-speed data at the same time. In these applications, Cat6 Unshielded Module provides extremely low signal attenuation, ensuring that data transmission remains efficient and stable even in complex network environments. 4. Durability and long-term stability support high transmission performanceThe durability of Cat6 Unshielded Module is also an important factor in ensuring its high transmission performance. The IDC terminal design of the module adopts cold pressing technology, so that the contact point can withstand at least 250 crimpings, and the contact pins can withstand at least 750 plugging and unplugging. Even in an environment with long-term frequent use, the module can still maintain stable transmission performance. 5. Wide compatibility for high-speed network applicationsIn addition to low insertion loss and high transmission performance, Cat6 Unshielded Module also has strong compatibility and can be widely adapted to various high-speed network applications. The module is designed to comply with international standards such as TIA/EIA-568B.2-1, EN50173, ISO/IEC 11801, and supports multiple high-speed data transmission standards including 10Base-T, 100Base-Tx, 1000Base-Tx, ATM, etc.
